External Cellular Antenna for Cellular EcoPort Module (US08Ba)

$9.99
Weight:
0.10 LBS
Shipping:
Calculated at checkout
Quantity:

Product Description

Optional external antenna for the SkyCentrics AC CTA-2045 Cellular EcoPort module
This external antenna is stronger than the in-built cellular antenna present in the Cellular EcoPort module. It is ideal for situations where a cellular signal is weak, but present

Please ensure that the external antenna is screwed in to the EcoPort module before the module is connected to a power source

SpecificationDetails
Frequency 4G / LTE / NB-IoT / 2G / 3G / GSM / GPRS
Frequency Range 698–960MHz; 800–960 MHz; 1710–2170MHz; 1710–2700 MHz
Gain 2.5 dBi / 3 dBi / 5 dBi
VSWR ≤ 1.5
Polarization Vertical Polarization
Radiation Pattern Omnidirectional
Impedance 50 Ω
Power Handling 20 W
Connector Type SMA-J
Antenna Material TPEE (Thermoplastic Polyester Elastomer)
